C (Cutter)
Max Flow Rate: 108.3L/sec (6.4m3/min)
Head Max: 64m
C Series
The C series is a submersible cutter pump for sewage and wastewater, which is made of casting and equipped with cutting mechanism. Featuring a combination of impeller vane with brazed sintered tungsten carbide alloy edge and a suction cover of serrated shape, the C series pumps enable smooth pumping, while cutting solid and fibrous matter during suction. The impeller and suction cover of the “CR” type are made of high-chromium cast iron, ensuring excellent durability and enabling the pump to maintain high performance for an extended period.
Note:
1. Not all the pumps listed in the catalogue are available for Australia. Models for Australia are listed below under ‘Models’
2. Product guides / catalogues may vary for Australia. Contact us for the latest technical data
| Discharge Bore (mm) | Model | Motor Output (kW) | Phase | Starting Method |
|---|---|---|---|---|
| 50 | 50C2.75S  | 0.75 | Single | Capacitor Start |
| 50 | 50C2.75 | 0.75 | Three | D.O.L. |
| 80 | 80C21.5 | 1.5 | Three | D.O.L. |
| 80 | 80C22.2-CR | 2.2 | Three | D.O.L. |
| 80 | 80C23.7-CR | 3.7 | Three | D.O.L. |
| 80 | 80C25.5-CR | 5.5 | Three | D.O.L. |
| 80 | 80C27.5-CR | 7.5 | Three | D.O.L. |
| 80 | 80C211-CR | 11 | Three | Star-Delta |
| 80 | 80C215-CR | 15 | Three | Star-Delta |
| 100 | 100C222-CR | 22 | Three | Star-Delta |
| 100 | 100C42.2 | 2.2 | Three | D.O.L. |
| 100 | 100C43.7 | 3.7 | Three | D.O.L. |
| 100 | 100C45.5 | 5.5 | Three | D.O.L. |
| 100 | 100C47.5 | 7.5 | Three | D.O.L. |
| 100 | 100C411 | 11 | Three | Star-Delta |
| 100 | 100C415 | 15 | Three | Star-Delta |
| 150 | 150C611-CR | 11 | Three | Star-Delta |
| 150 | 150C615-CR | 15 | Three | Star-Delta |
| 200 | 200C437-CR | 37 | Three | Star-Delta |
Notes:
Icon identifies single phase pumps in compliance with AS/NZS 4417.1 & 2- Guide Rail Fittings available
