MQ Series – Submersible IE3 Sewage Pumps
High-efficiency wastewater & sewage pumping solutions
The MQ-series, of the Tsurumi Avant brand, is a submersible sewage pump with an IE3 premium high-efficiency electric motor, designed to deliver high performances and withstand continuous duty cycles. Overall efficiency and energy-savings have been taken to new heights by pursuing greater efficiency in both the pump and motor. Moreover, to ensure users get what they are looking for, the MQ-series offers 5 types of impellers (Open Channel, Chopper, Vortex, Grinder and High Head) and super wide ranges of specifications featuring 50 to 500 mm discharge bore diameters and 1.1 to 355 kW motor output specifications. Pump installation can be chosen between a WET version that submerges the pump in water or a DRY version that installs the pump indoors or outside the tank using the original closed loop cooling system with internal recirculation.
Open channel impeller pumps have new and innovative Anti-Clogging System. This ACS uses the centrifugal force of the impeller to pull out the stringy material via spiral groove of suitable depth cut into the diffuser plate. This effective measure eradicates the fibrous material clogging of the impeller.
Contact us for a pump selection.
Typical Applications
- Civil and industrial wastewater treatment plants
- Lifing stations
- Pumping sludges and biological liquids
- Rainwater containing solids
- Raw recycling
- Sewage and wastewater plants
Note:
1. Not all the pumps listed in the catalogue are available for Australia. Reach out to us for a pump selection
2. Product guides / catalogues may vary for Australia. Contact us for the latest technical data
Why Choose Tsurumi
Tsurumi pumps are known worldwide for their reliability, ease of maintenance and long service life. With more than a century of engineering experience, Tsurumi is trusted by contractors, councils and operators across Australia. Customers also benefit from national spare-parts support and fast delivery.
Proven Tsurumi Reliability
Tsurumi pumps are used on job sites across Australia and around the world. The MQ series submersible sewage pumps are an excellent choice for applications requiring versatile and customisable pump solutions.
