PN
Max Flow Rate: 15L/sec (0.9m3/min)
Head Max: 26.1m
PN Series
The PN-series is made of special resin and stainless steel, it is corrosion-resistant and lightweight. It is a semi-vortex pump, which is constructed of a vortex impeller and low-height volute casing. The semi-vortex pump design with moderate solids passage provides efficient performance for versatile applications.
| Discharge Bore(mm) | 40 – 80 |
|---|---|
| Motor Output(kW) | 0.25 – 3.7 |
Note:
1. Not all the pumps listed in the catalogue are available for Australia. Models for Australia are listed below under ‘Models’
2. Product guides / catalogues may vary for Australia. Contact us for the latest technical data
| Discharge Bore (mm) | Manual Model | Motor Output (kW) | Phase | Starting Method | Solids Passage (mm) |
|---|---|---|---|---|---|
| 40 | 40PN2.25S  | 0.25 | Single | Capacitor Run | 10 |
| 40 | 40PN2.25 | 0.25 | Three | D.O.L. | 10 |
| 50 | 50PN2.4S | 0.4 | Single | Capacitor Run | 10 |
| 50 | 50PN2.4 | 0.4 | Three | D.O.L. | 10 |
| 50 | 50PN2.75S | 0.75 | Single | Capacitor Run | 10 |
| 50 | 50PN2.75 | 0.75 | Three | D.O.L. | 10 |
| 50 | 50PN21.5 | 1.5 | Three | D.O.L. | 20 |
| 80 | 80PN22.2 | 2.2 | Three | D.O.L. | 20 |
| 80 | 80PN23.7 | 3.7 | Three | D.O.L. | 20 |
Notes:
Icon identifies single phase pumps in compliance with AS/NZS 4417.1 & 2- Automatic, Auto‐Alternation, or Guide Rail Fitting models available. Refer to catalogue for further information
View how the automatic & auto-alternation models work.
